NS9307A|新声

NS9307A

Overview：

The NS9307A is a high-performance, New Sonic Acoustic Resonator (NewSAR) Duplexer for LTE B7 TRX application with low insertion loss and high isolation.

The NS9307A uses common module packaging techniques to achieve the industry standard 1.8 x 1.4 mm footprint. The filter exhibits excellent power handling capabilities.

Specification：

Function
```
Duplexer
```
Band
```
B7
```
Technology
```
BAW
```
Package
```
CSP 1.8 x 1.4 mm
```
Insertion Loss(dB)
```
2.08/2.34
```
Termination Impedance
```
Unbalanced
```
Status
```
Production
```
Packing Quantity
```
5000
```
